产品中心 储能电源 EV-90A
EV-90A
EV-90A
大容量可移动充电；能给汽车充电；可应急救援供电；可 DC快充

用户手册

产品视频

询价

01
产品介绍
Product Introduction
EV-90A
  • 可移动充电
    可移动充电
  • 能给汽车充电
    能给汽车充电
  • 应急救援供电
    应急救援供电
  • 可 DC快充
    可 DC快充
02
参数介绍
Parameter Introduction
Product name EV-90A-100D-R
Charging voltage DC CHARGER/AC380V
Charging standard GB/T(American/European/Japanese Standard）
Type of Battery LiFePO4
Nominal capacity 100KWh
Charge rate 0.5C
Discharge rate 1C
Battery voltage 614.4V
Depth of discharge 80%
Charge Cycles 5000
Cell type LiFePO4
Pack voltage 614.4V
Rated voltage 3.2V
Rated frequency 105A
Cooling method LIQUID COOLANT
IP level IP54
Isolation method Direct Detection
Rated Power 100 KW
Output Voltage DC200V-1000V
Output Current 0-200A
Charging mode 90KW DC Fast Charging
Safety Protections Overvoltage Overcurrent Low-voltage ESD Lighting Overcharge Overload Fire Overheat Waterproof Leakage and Chip Protection
Payment method OCPP
Networking method 4G Module
Networking protocol OCPP Network
Charging GUN GB/T(American/European/Japanese Standard）
Cable Length 5 Meters(Customizable)
HMI 7-inch touch screen (charging station)
Language Chinese (Customizable)
Dimension L*W*H/mm 2035*920*1491
Weight/kG ≈1450KG
Operating temperature/°C -10°C-60°C
Altitude/m 2000m
Noise/dB ≤60dB
Relative humidity/RH 5%～95% RH Non-condensing
Certificate CE
×
